BS LITE AND ASTM A53A SCH40 GPE FENCE TUBES

SIZE（OD” * WT” * L(FT) OD Wall Thickness Length PCS/ BUNDLE TONS/ BUNDLE
inch mm inch mm FT mm
BS LITE FENCE TUBES 1.315″X.104″X18′ 1.315 33.4 0.104 2.64 18 5486 91 1.000
1.660″X.104″X18′ 1.660 42.2 0.104 2.64 18 5486 61 0.862
1.900″X.116″X18′ 1.900 48.3 0.116 2.95 18 5486 61 1.104
2.375″X.116″X18′ 2.375 60.3 0.116 2.95 18 5486 37 0.847
2.875″X.128″X18′ 2.875 73 0.128 3.25 18 5486 19 0.583
1.315″X.104″X21′ 1.315 33.4 0.104 2.64 21 6400 91 1.166
1.660″X.104″X21′ 1.660 42.2 0.104 2.64 21 6400 61 1.005
1.900″X.116″X21′ 1.900 48.3 0.116 2.95 21 6400 61 1.288
2.375″X.116″X21′ 2.375 60.3 0.116 2.95 21 6400 37 0.988
2.875″X.128″X21′ 2.875 73 0.128 3.25 21 6400 19 0.680
1.315″X.104″X24′ 1.315 33.4 0.104 2.64 24 7315 91 1.333
1.660″X.104″X24′ 1.660 42.2 0.104 2.64 24 7315 61 1.149
1.900″X.116″X24′ 1.900 48.3 0.116 2.95 24 7315 61 1.472
2.375″X.116″X24′ 2.375 60.3 0.116 2.95 24 7315 37 1.129
2.875″X.128″X24′ 2.875 73 0.128 3.25 24 7315 19 0.777

1. Hot dipped galvanized.

2. Plain Ends.

3. Plastic sheet covered and the packaged by 3+2+2+3 Gal steel strips.

4. Shipped by 20GP or 40GP or by bulk.

Fence Panel

Panels:12″*6″，10″*6″，10″*8″

 Stands:30″*16″,36″*16″

SIZE（OD” * WT” * L(FT) OD Wall Thickness Length PCS/ BUNDLE TONS/ BUNDLE
inch mm inch mm FT mm
ASTM A53A SCH40 GPE 1″XSCH40X18′ 1 33.4 0.133 3.38 18 5486 60 0.824
11/4″XSCH40X18′ 11/4 42.2 0.140 3.56 18 5486 42 0.782
11/2″XSCH40X18′ 11/2 48.3 0.145 3.68 18 5486 36 0.800
2″XSCH40X18′ 2 60.3 0.154 3.91 18 5486 26 0.776
21/2″XSCH40X18′ 21/2 73 0.203 5.16 18 5486 18 0.852
3″XSCH40X18′ 3 88.9 0.216 5.49 18 5486 14 0.867
31/2″XSCH40X18′ 31/2 101.6 0.226 5.74 18 5486 12 0.893
4″XSCH40X18′ 4 114.3 0.237 6.02 18 5486 10 0.882
6″XSCH40X18′ 6 168.3 0.280 7.11 18 5486 7 1.085
8″XSCH40X18′ 8 219.1 0.322 8.18 18 5486 5 1.167
1″XSCH40X21′ 1 33.4 0.133 3.38 21 6400 60 0.961
1 1/4″XSCH40X21′ 11/4 42.2 0.140 3.56 21 6400 42 0.912
1 1/2″XSCH40X21′ 11/2 48.3 0.145 3.68 21 6400 36 0.933
2″XSCH40X21′ 2 60.3 0.154 3.91 21 6400 26 0.905
21/2″XSCH40X21′ 21/2 73 0.203 5.16 21 6400 18 0.994
3″XSCH40X21′ 3 88.9 0.216 5.49 21 6400 14 1.012
31/2″XSCH40X21′ 31/2 101.6 0.226 5.74 21 6400 12 1.042
4″XSCH40X21′ 4 114.3 0.237 6.02 21 6400 10 1.029
6″XSCH40X21′ 6 168.3 0.280 7.11 21 6400 7 1.266
8″XSCH40X21′ 8 219.1 0.322 8.18 21 6400 5 1.361
1″XSCH40X24′ 1 33.4 0.133 3.38 24 7315 60 1.098
11/4″XSCH40X24′ 11/4 42.2 0.140 3.56 24 7315 42 1.042
11/2″XSCH40X24′ 11/2 48.3 0.145 3.68 24 7315 36 1.066
2″XSCH40X24′ 2 60.3 0.154 3.91 24 7315 26 1.034
21/2″XSCH40X24′ 21/2 73 0.203 5.16 24 7315 18 1.137
3″XSCH40X24′ 3 88.9 0.216 5.49 24 7315 14 1.156
31/2″XSCH40X24′ 31/2 101.6 0.226 5.74 24 7315 12 1.191
4″XSCH40X24′ 4 114.3 0.237 6.02 24 7315 10 1.176
6″XSCH40X24′ 6 168.3 0.280 7.11 24 7315 7 1.447
8″XSCH40X24′ 8 219.1 0.322 8.18 24 7315 5 1.556
Fence Tubes And Panel
